ENERPAC® PUJ PUJ1400E Hydraulic Pump, 208 to 240 V, 0.5 hp, 116 cu-in Reservoir, 10000 psi Max Operating Pressure

  • Part#: PUJ1400E
  • Min. Order Qty: 1
  • Qty. Interval: 1
  • Availability: loading

The Economy pump is excellent suited to power small to medium size cylinders or hydraulic tools. Its lightweight and compact design makes it ideal for applications which require easy transport of the pump. The Universal motor works well on long extension cords or generator driven electrical power supplies.

ENERPAC® PUJ Hydraulic Pump, HP Rating: 0.5 hp, 208 to 240 V, 50/60 Hz Frequency, Maximum Operating Pressure: 10000 psi, Maximum Flow Rate: 20 cu-in/min, 116 cu-in Reservoir, Usable Oil Capacity: 0.5 gal, Cylinder Compatibility: Double-Acting, 4-Way, 3-Position Valve, Valve Operation: Manual, Valve Function: Advance, Hold, Retract, Pump Control Type: Pendant, 85 dBA Sound Level, 9.62 in Length, 9.62 in Width, 14-1/4 in Height

Cylinder Compatibility      :      Double-Acting
Frequency Rating      :      50/60 Hz
HP Rating      :      0.5 hp
Height      :      14-1/4 in
Length      :      9.62 in
Maximum Flow Rate      :      20 cu-in/min
Maximum Operating Pressure      :      10000 psi
Pump Control Type      :      Pendant
Reservoir Capacity      :      116 cu-in
Series      :      PUJ
Sound Level      :      85 dBA
Usable Oil Capacity      :      0.5 gal
Valve Function      :      Advance, Hold, Retract
Valve Operation      :      Manual
Valve Type      :      4-Way, 3-Position
Voltage Rating      :      208 to 240 V
Width      :      9.62 in
  • Manual valves provide advance-hold-retract tool operation
  • 3 m cord with pendant controls the motor operation
  • Lightweight and compact design - 11.8 to 18.6 kg
  • Large easy-carry handle for maximum portability
  • Two-speed operation reduces cycle time for improved productivity
  • 230 VAC 50/60-cycle universal motor will operate under poor voltage supply
  • 24 VAC remote motor control, 3 m L for operator safety
  • Starts under full load
  • High-strength molded shroud with integral handle, protects motor from contamination and damage
  • Designed for intermittent-duty cycle
